Lead-free Wave Soldering Machine HWU-350/450
We have a full range of wave solder machine, nitrogen is an option, please contact us to discuss your individual requirement.
The guide rail can bear up to 80kg, new heavy finger, anti-shaking, ball chain structure.
Low dross oxidization, new wave nozzle design, the pot has automatic in, out, lifting function.
Selective area spray, flux can save up to 70%.
Free combination of hot air and infrared preheating module.
Segmented transportation rail design, 80kg rail transportation capacity, the maximum width of PCB can be increased to 610mm.
With advance temperature controller, counter, timer, and speed controller etc., provide a stable performance of the machine.
Solder pot we provide titanium and cast iron for option.
Light and sound alarm for overheating and emergency stop.
The conveyor system is equipped with overload protection.
Model | HWU-350 | HWU-450 |
| Machine parameter | ||
Dimension (L x W x H)mm | 4500x1500x1800mm | |
Power supply | 3 phase, 380V 50/60HZ | |
General power | 25KW | |
Startup power | 15KW | |
Normal power consumption | Approx.3-8KW | |
| Preheat system parameters | ||
Preheat mode | Hot air | |
Speed control | stepless frequency | |
Preheat zone No. | 4 | |
Preheat length | 1800mm | |
Preheat temp | Room temp – 250℃ | |
| Soldering system | ||
Solder pot-driven mode | Mechanical pump | |
Solder pot material | titanium | |
Heater power | Case iron:14.5KW; titanium:12KW | Case iron: 14.5KW; titanium:15KW |
Pot volume | 500-550kg | |
Temp control mode | PID + SSR | |
Warm-up time | About 90Min (set 250℃) | |
| Conveyor system | ||
PCB width | 50-350mm | 50-450mm |
Component height | top:120mm, bottom:25±5mm | |
Conveyor speed | 0-1800mm.min | |
Conveyor height | 750±20mm (option: 900±20mm) | |
Conveyor type | Titanium finger | |
Solder angle | 3-7° | |
PCB direction | L to R or R to L | |
Conveyor motor power | 120V 3P 220VAC | |
| N2 system (option) | ||
Nitrogen consumption | 15m3/h, <1000PPM | |
Nitrogen supply | 0.5-0.8Kpa | |
| Others | ||
Flux auto feeding | Yes | |
Flux flow | 20-100ml/min | |
Spray pressure | 0.25-0.4MPa | |
Cooling (option) | 2HP 2P 220VAC | |
Center support | Option | |
