Automatic Screw Locking Machine
We also provide SMT PCBA coating line solution based on customers’ products, such as: PCBA loading conveyor+ selective coating machine + Sealing inspection conveyor + UV Curing machine +flipper + selective coating machine + Sealing inspection conveyor + UV Curing machine + PCBA unloading conveyor.
X, Y, Z motion system, with high-precision servo drive and screw module drive, accurately avoiding non-coating areas.
Realize multi-track spraying such as spot coating, line coating, curve coating, etc., can be used in the high-density complex circuit board coating process.
Intelligent variable speed, high speed conveying in non-coating area to save time and improve production capacity.
With high speed, high reliability, high stability transmission and control system.
Programming mode: software program with a data input manual instructional programming.
Equipment with automatic wide adjustment function.
Inline operation with SMEMA communication.
Model | HW-C930 |
Machine Dims | L1060mm*1240mm*1700mm |
Platform | T25mm polished and chrome-plated steel plate |
Control mode | Industrial PC + motion control card |
Programmer storage | >1000 |
Rail track | Special aluminum alloy rail and 35B5 stainless steel chain |
Transfer high | 920±20mm |
Transfer speed | 0-5m/min |
Transfer direction | L to R or R to L |
Conveyor mode | Chain (35B5mm extension pin stainless steel chain) |
Guide rail width | 50-450mm automatic adjustment |
Transfer Motor | 2 units step motor |
X.Y axis drive mode | Servo motor + precision fully closed screw module drive |
X.Y axis max speed | 800mm/s |
X.Y axis locate accuracy | ±0.02mm |
Z axis max speed | 300mm/s |
Valve | 1pc atomization valve+ 1pc dispensing valve (qty can be specified) |
PCB size | 50*50 – 450*450mm |
Component height | within ±100mm |
Spray width | 3-10mm |
Barrel volume | 1pc 10L stainless steel inner drum with mixing function |
Cleaning function | With cleaning function |
Light part | With light |
Detection part | equipped with fluorescent agent detection light source |
Net weight | Approx.650kg |
Power supply | AC220V 50HZ |
Air supply | 4-6kgf/cm2 |
Total power | 1.8kw |
