HW Series Ultra-High-Speed Pick-and-Place Machines
Ultra High Speed Pick-and-Place Machine
Max Speed: 84,000 CPH (Dual-arm configuration)
Key Technologies:
Dual linear motors + grating scales for XY-axis
Maglev motion modules
10-head high-speed placement with flying cameras
Supports 0201 chips (0.35×0.25mm) to 40×40mm components
Unique Features:
Dual-lane production (independent/alternate modes)
AI-powered path optimization algorithms
MES system integration for smart factory management
±0.035mm placement accuracy
Max Speed: 42,000 CPH
Key Advantages:
Linear motor XY-axis (industry-first dual configuration)
10-nozzle high-speed head + 6-nozzle multi-function head
5MP flying camera + 6MP fixed camera system
Automatic warpage compensation (±0.03mm accuracy)
Max Speed: 40,000 CPH
Best For:
LED-specific production (strips/bulbs/drivers)
8-head vision system with 360° placement
±0.05mm accuracy with granite base stability
Max Speed: 12,000 CPH (Vision-enabled)
Special Capabilities:
Nozzle-free design for quick changeovers
Dual micro-cylinder clamping system
WYSIWYG programming interface
Motion Systems: Linear motors (HW-F5/S5/S6) vs servo motors (A-series)
Vision Tech: Flying cameras enable on-the-fly correction without speed loss
Automation:
ATC nozzle changers (40-nozzle capacity)
Smart feeder systems with 88mm tape support
Vacuum monitoring with self-check functions
For maximum throughput, the HW-S5/S6 dual-arm models with 84K CPH and AI-optimized paths represent the ultimate ultra-high-speed solution, while the HW-F5 provides premium single-arm performance.
Discover the best in SMT technology with HW’s innovative pick-and-place machines, designed for unparalleled speed and precision in manufacturing.
